Cupro Nickel 70/30 Seamless Pipes
The higher-duty cupro nickel. Tripling the nickel to 30% raises strength, erosion-corrosion resistance and the allowable seawater velocity to around 4.5 m/s, and lifts the service temperature well above 90/10. It is the grade for pump and valve-adjacent piping, hot brine and MSF desalination heat recovery, and any line where turbulence or sand loading would strip the film off 90/10.
- Higher allowable seawater velocity than 90/10 (about 4.5 m/s)
- Better erosion-corrosion resistance in turbulent and sand-laden flow
- Retains strength and film stability at elevated temperature
- Biofouling resistant and immune to chloride stress corrosion cracking
- Supplied as seamless pipe, condenser tube, plate, fittings and flanges
Available forms & sizes
| Form | Size range |
|---|---|
| Seamless Pipes & Tubes | 1/8" - 12" NB seamless, 6 - 108 mm OD tube, 0.8 - 6 mm wall |
| Welded Pipes | 4" - 36" OD welded pipe to ASTM B467 |
| Plates | 3 - 50 mm thk condenser plate and tube sheet (ASTM B171) |
| Sheets & Coils | 0.6 - 3 mm thk sheet and coil |
| Flanges | 1/2" - 24", 150# - 300#, slip-on and weld neck |
| Fittings | 1/2" - 24" butt weld elbows, tees, reducers and stub ends |
| Round Bars | 10 - 200 mm dia rod and bar |
Chemical composition (%)
| Element | Min | Max |
|---|---|---|
| Cu | Remainder | - |
| Ni | 29.0 | 33.0 |
| Fe | 0.40 | 1.00 |
| Mn | 0.50 | 1.50 |
| Pb | - | 0.02 |
Mechanical properties
| Property | Value | Unit |
|---|---|---|
| Yield Strength (0.2%) | 140 min (annealed) | MPa |
| Tensile Strength | 380 min (annealed) | MPa |
| Elongation | 30 min | % |
| Hardness | 80 - 110 | HV |
Physical properties
| Property | Value | Unit |
|---|---|---|
| Density | 8.94 | g/cm3 |
| Thermal Conductivity | 29 | W/m.K |
| Max Service Temperature | 400 | C |
| Max seawater velocity | 4.0 - 4.5 | m/s |
Typical applications
